Insertion Flow Meter
| Model | SR1000i |
| Brand | manas microsystems |
| Application Media | Water |
| Weld in socket | SS 304 |
| Media Pressure | 15 kg/cm2 |
| Media Temperature | 0 to 80 deg C |
| Ambient Temperature Range | 0 to 50 deg C |
| Electrodes | SS 316 |
| Wetted Parts | SS 304, SS 316, Epoxy |
| Insertion Probe Material | SS 304 |
| Flange Mounting Assembly | SS 304 |
| Power Supply to Field Coils | Pulsed DC |
| Terminal box | IP-68 |
| Line Size | DN200 |
Feature
| Model | SR1000i |
| Brand | manas microsystems |
| Application Media | Water |
| Weld in socket | SS 304 |
| Media Pressure | 15 kg/cm2 |
| Media Temperature | 0 to 80 deg C |
| Ambient Temperature Range | 0 to 50 deg C |
| Electrodes | SS 316 |
| Wetted Parts | SS 304, SS 316, Epoxy |
| Insertion Probe Material | SS 304 |
| Flange Mounting Assembly | SS 304 |
| Power Supply to Field Coils | Pulsed DC |
| Terminal box | IP-68 |
| Line Size | DN200 |
Description
Specifications:
| Dia.(mm) | m³/hr | MLD | Cu.ft./Sec. |
| 200 | 113.097 | 2.7143 | 1.1094 |
| 250 | 176.714 | 4.2411 | 1.7335 |
| 300 | 254.469 | 6.1072 | 2.4962 |
| 350 | 346.36 | 8.3126 | 3.3977 |
| 400 | 452.389 | 10.8573 | 4.4378 |
| 500 | 706.858 | 16.9646 | 6.934 |
| 600 | 1017.875 | 24.429 | 9.985 |
| 700 | 1385.441 | 33.2506 | 13.5907 |
Technical Details:
| Dia.(mm) | m³/hr | MLD | Cu.ft./Sec. |
| 800 | 1809.556 | 43.4293 | 17.7511 |
| 900 | 2290.219 | 54.9652 | 22.4662 |
| 1000 | 2827.431 | 67.8583 | 27.736 |
| 1200 | 4071.5 | 97.716 | 39.94 |
| 1400 | 5541.765 | 133.0024 | 54.3626 |
| 1600 | 7238.223 | 173.7174 | 71.0043 |
| 1800 | 9160.876 | 219.861 | 89.8648 |
| 2000 | 11309.724 | 271.4333 | 110.9442 |
